JRready JST1030 Crimp Tool Kit (JRD-ASF1 M22520/1-01 Crimp Tool+TH163 Turret Head) 12-26awg, crimp 12#, 16#, 20# Pin / Socket in M38999 SERIES 1,3,4 CONNECTORS

Name: JRready JST1030 Crimp Tool Kit (JRD-ASF1 M22520/1-01 Crimp Tool+TH163 Turret Head) 12-26awg, crimp 12#, 16#, 20# Pin / Socket in M38999 SERIES 1,3,4 CONNECTORS
Brand: JRready tools
Price: 220.0 USD
Availability: InStock

$220.00

TYPE

1 PACK

3 PACK

5 PACK

Quantity

[{"id":39394335359049,"title":"1 PACK","option1":"1 PACK","option2":null,"option3":null,"sku":"ST1030S28A","requires_shipping":true,"taxable":false,"featured_image":{"id":28400252223561,"product_id":6598380781641,"position":1,"created_at":"2021-08-26T14:07:13+08:00","updated_at":"2021-08-26T14:07:59+08:00","alt":null,"width":901,"height":901,"src":"\/\/www.jrdtools.com\/cdn\/shop\/products\/JST1030_31c3aebf-207b-4506-b76c-34f98f3f8dd6.jpg?v=1629958079","variant_ids":[39394335359049,39394335391817,39394335424585]},"available":true,"name":"JRready JST1030 Crimp Tool Kit (JRD-ASF1 M22520\/1-01 Crimp Tool+TH163 Turret Head) 12-26awg, crimp 12#, 16#, 20# Pin \/ Socket in M38999 SERIES 1,3,4 CONNECTORS - 1 PACK","public_title":"1 PACK","options":["1 PACK"],"price":22000,"weight":1000,"compare_at_price":null,"inventory_management":"shopify","barcode":"7618423884744","featured_media":{"alt":null,"id":20670574755913,"position":1,"preview_image":{"aspect_ratio":1.0,"height":901,"width":901,"src":"\/\/www.jrdtools.com\/cdn\/shop\/products\/JST1030_31c3aebf-207b-4506-b76c-34f98f3f8dd6.jpg?v=1629958079"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":39394335391817,"title":"3 PACK","option1":"3 PACK","option2":null,"option3":null,"sku":"ST1030S28B","requires_shipping":true,"taxable":false,"featured_image":{"id":28400252223561,"product_id":6598380781641,"position":1,"created_at":"2021-08-26T14:07:13+08:00","updated_at":"2021-08-26T14:07:59+08:00","alt":null,"width":901,"height":901,"src":"\/\/www.jrdtools.com\/cdn\/shop\/products\/JST1030_31c3aebf-207b-4506-b76c-34f98f3f8dd6.jpg?v=1629958079","variant_ids":[39394335359049,39394335391817,39394335424585]},"available":true,"name":"JRready JST1030 Crimp Tool Kit (JRD-ASF1 M22520\/1-01 Crimp Tool+TH163 Turret Head) 12-26awg, crimp 12#, 16#, 20# Pin \/ Socket in M38999 SERIES 1,3,4 CONNECTORS - 3 PACK","public_title":"3 PACK","options":["3 PACK"],"price":61500,"weight":1000,"compare_at_price":null,"inventory_management":"shopify","barcode":"7771070069794","featured_media":{"alt":null,"id":20670574755913,"position":1,"preview_image":{"aspect_ratio":1.0,"height":901,"width":901,"src":"\/\/www.jrdtools.com\/cdn\/shop\/products\/JST1030_31c3aebf-207b-4506-b76c-34f98f3f8dd6.jpg?v=1629958079"}},"requires_selling_plan":false,"selling_plan_allocations":[]},{"id":39394335424585,"title":"5 PACK","option1":"5 PACK","option2":null,"option3":null,"sku":"ST1030S28C","requires_shipping":true,"taxable":false,"featured_image":{"id":28400252223561,"product_id":6598380781641,"position":1,"created_at":"2021-08-26T14:07:13+08:00","updated_at":"2021-08-26T14:07:59+08:00","alt":null,"width":901,"height":901,"src":"\/\/www.jrdtools.com\/cdn\/shop\/products\/JST1030_31c3aebf-207b-4506-b76c-34f98f3f8dd6.jpg?v=1629958079","variant_ids":[39394335359049,39394335391817,39394335424585]},"available":true,"name":"JRready JST1030 Crimp Tool Kit (JRD-ASF1 M22520\/1-01 Crimp Tool+TH163 Turret Head) 12-26awg, crimp 12#, 16#, 20# Pin \/ Socket in M38999 SERIES 1,3,4 CONNECTORS - 5 PACK","public_title":"5 PACK","options":["5 PACK"],"price":99900,"weight":1000,"compare_at_price":null,"inventory_management":"shopify","barcode":"7337004974307","featured_media":{"alt":null,"id":20670574755913,"position":1,"preview_image":{"aspect_ratio":1.0,"height":901,"width":901,"src":"\/\/www.jrdtools.com\/cdn\/shop\/products\/JST1030_31c3aebf-207b-4506-b76c-34f98f3f8dd6.jpg?v=1629958079"}},"requires_selling_plan":false,"selling_plan_allocations":[]}]

JRD-ASF1 Hand Crimp Tool

1.Has limitless application within the specified wire range of 12-26 AWG
2.Positioners adapt the tool frame to specific military or proprietary contact combination
3.The JRD-ASF1 gives an 8 impression crimp, which assures maximum tensile strength
4.Crimp depth can be adjusted by an 8 position selector knob conveniently located on the tool frame
5.Often used in military institutions, aviation companies and electronic connector companies
6.The precision ratchet controls cycling of the tool in both directions of handle movement which assures the same accurate crimp every time

TH163 Turret Head

1.Adjustable positioner,Designing according to MIL standard M22520/1-04
2.Gives a standardized and accurate crimp every time
3.A dataplate affixed to turret head lists specific contact part numbers, the corresponding position color code, and suggested selector depth settings for the wire size being used
4.Can be adjusted to match the diameter of the connectors and the wires desired

Specifications:
● Material: Mould Steel
● AWG: 12-26AWG(0.128-3.33mm²)
● Crimper Through-hole Dia: Φ5.6mm
● Dimensions(mm): 247*59*25(crimper),50.8*30.8(positioner)
● Weight(g): 543(crimper),110(positioner)

Specific Application Details:
1.Used to crimp 12#, 16#, 20# Pin / Socket in MIL-PRF-38999 SERIES 1,3,4 CONNECTORS.
2.Contacts Part Number: M39029/58-365, M39029/56-353, M39029/58-364, M39029/56-352, M39029/58-363,M39029/56-351. M39029/63-368

Guarantee:
❤ Our tools Warranty period is 1 year(not include indenters ,crimping axis , etc. vulnerable parts)
❤ JRready guarantees all buyers 100% satisfaction, once you find any problem of the product, please feel free to contact us, we would try our best to assist you.
