JRready tools

YJQ-MH800 Miniature Adjustable Crimp Tool ULTRA-PRECISION Crimper Wire Range 20-32 AWG

Regular price $199.00
/

  • 4-indent 8-impression crimp style
  • Wire Range 20-32 AWG
  • Crimp depth is controlled by an 8 position selector knob
  • Tool is compatible with YJQ-W1A/afm8 positioners
  • Compared with YJQ-W1A, YJQ-MH800 has a smaller gaging limits of indents

    ULTRA-PULTRA-PRECISION Crimping Tool YJQ-MH800

    TOOL PRINCIPLE :The crimping tool adopts curve propulsion mechanism, its applied force transfers through four curves in the head cavity of the right plier handle to the four indenters. The four intenders do the centripetal linear motion, which makes its front-end teeth crimp the contact to complete the crimping process. The cycle controlled precision ratchet assures the consistency of impression and the crimping quality of wires and contacts.
    GO-NOGO GAGUE:G100(NOT SUPPLTED WITH TOOL)
    GAGING LIMITS OF INDENTERS(mm/inch):
    A (GO) B (NO GO)
    1 0.36/0.014 0.41/0.016
    2 0.43/0.017 0.48/0.019
    3 0.51/0.020 0.56/0.022
    4 0.58/0.023 0.63/0.025
    5 0.68/0.027 0.73/0.029
    6 0.79/0.031 0.84/0.033
    7 0.89/0.035 0.94/0.037
    8 1.01/0.040 1.06/0.042
